All around GPU Virtualization technologies, support major deployment Scenarios:
From desktop to edge and data center, a fully open ecosystem for pervasive AI applications.
 |
| ASIC | NAVI 22 | |
| Form Factor | Active/Passive cooling, Dual Slot, Full Height，L:270MM | |
| Power | 170W | |
| GPU Architecture | RDNA2 | |
| stream processor | 2304 | |
| GPU Clock | 2132 MHz (Base) / 2293 MHz (Game) / 2425MHz (Boost) | |
| Memory: Size/Type Per GPU | 10 GB GDDR6 | |
| Memory: Speed | 16Gbps | |
| Memory: Bandwidth | 320GB/s + Infinity Cache | |
| Power Connector | 2×8 Pin | |
| Encode: VCN Clock | 1200 MHz | |
| Encode: Engines | 2x VCN3.0: H.264, H.265 (HEVC) | |
| Encode: Stream | (24) H.264/265 1080p30 4:2:0; (54) H.264/265 720p30 4:2:0 | |
| Encode: Remoting Protocols | Teradici PCoIP, Citrix HDX 3D Pro, RDP, AMD Streaming SDK | |
| New Features | HW Raytracing, DX12 Ultimate, CustomizationStreaming SDK，Customization Driver | |
| Hypervisor | KVM | |
| Supported OS | Win 10, Win 11 | |
| API Support | Direct3D, Vulkan, OpenGL, OpenCL | |
  |
| Performance | |
| GPUs per board | 1 |
| Max GPU VM’s per board | 12 |
| Stream processors | 4608 |
| Compute Units | 72 |
| Ray Accelerators | 72 |
| Multi-VF encode | Yes |
| Peak Clock Speed | 2,200MHz |
| AMD Infinity Cache | 128mb |
| Memory | |
| Memory Size/Type per GPU | 32GB GDDR6 |
| Memory Bandwidth | 512GB/s |
| Memory Interface | 256-bit |
| Memory Speed | 16 Gbps |
| Supported Rendering Format | |
| H265/HEVC Encode | Yes |
| 4K H264 Encode | Yes |
| VNC Engine | 2 |
| Supported OS | |
| Remoting | Microsoft RDP®, No Machine |
| Guest OS | Microsoft Windows® Server 2019, Ubuntu® 20.04, Linux CentOS |
| Hypervisor | KVM, Hyper-V |
| Board Design | |
| Display Connectors | None |
| PCI Express® Interface | PCIe® Gen4 x16 |
| Board Power | Peak board power 300W |
| Power Connector | 2x 8 Pin |
| Form Factor | Passive, 4.4 Full Height, Dual Slot, 10.5” Length |
| API Support | DirectX® 11/12 (Windows), Vulkan®, OpenCL™, OpenGL® |
 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
